8KW Grid-Tie Solar Inverter

Grid Tie Inverter Three Phase

About 8KW Solar Inverter

The 8kW grid-tie solar inverter is a high-performance energy solution designed for larger residential and small commercial systems. Exclusively available in a Three Phase configuration, this inverter ensures balanced power distribution and enhanced energy efficiency, making it perfect for setups with higher energy demands.

Configurations:

  • Three Phase:
    Tailored for larger homes or small businesses, the three-phase configuration provides consistent power distribution and improved system performance. It efficiently integrates solar energy with the grid while reducing energy costs.

Authorized V-Sole Dealer

As an authorized dealer of V-Sole inverters, we offer cutting-edge solar solutions built with advanced technology, exceptional reliability, and robust durability. V-Sole inverters are trusted for their seamless performance, making them an ideal choice for modern energy systems.

The 8kW Grid-Tie Solar Inverter is designed to deliver superior efficiency, reliable operation, and long-term energy savings. Its compact design and user-friendly interface make it a smart investment for sustainable energy needs.

Choose the 8kW Grid-Tie Solar Inverter today and experience the benefits of clean, efficient, and cost-effective energy management.

BROCHURE
For More Info:
Contact Us

GRID TIE INVERTER - THREE PHASE

Advanced Features:

  • Maximum efficiency reaches up to 98.9%, ensuring optimal energy conversion.
  • Comes with a heavy-duty, built-in DC isolation switch for enhanced safety.
  • special external color with Epoxy Novolac coating for better heat dissipation and durability.
  • Supports a maximum DC input current per string, compatible with solar panels up to 800W.
  • Equipped with Type II DC/AC SPD and frequency drop control technology for better protection.
  • Higher capacity models include intelligent fan-based cooling for efficient heat management.
  • Compact, lightweight design allows for easy installation and space-saving.
  • Supports RS485 and remote monitoring via Wi-Fi or GPRS for easy control and tracking.
  • Includes multiple protective features to ensure the system operates safely and efficiently.
  • Allows for DC overloading up to 20%, providing flexibility in handling high loads.

Technical Specification:

8KW Inverter Specifications
CAPACITY (KW) 8KW
MODEL NUMBER VS-082T
INPUT (DC)
Max. DC Input Power (KW) 9.6
Max. DC I/P (Vdc) 1000V
Max. MPPT I/P Current (A) 20A + 26A
MPPT Short Circuit Current (A) 30A + 39A
MPPT Tracking Voltage (Vdc) 180 – 1000V
Start-Up Voltage (V) 200V
Number of MPPT Tracker 2
Strings per MPPT Tracker 1 + 2
OUTPUT (AC)
Rated Output Power (KW) 8
Rated Grid Voltage (V) / Range 415V
Voltage Operating Range (V) 280 – 455V
Rated Grid Frequency (Hz) / Range 50Hz (+-5%)
Rated Output Current AC (A) 12.2
AC Connection 3P + N + PE
THDI (%) <3%
Output Power Factor 0.9 leading to 0.9 lagging
EFFICIENCY
Max. Conversion Efficiency (%) 98.3%
Max. Euro Efficiency (%) 97.5%
MPPT Efficiency (%) >99%
PROTECTION
Anti-Islanding Protection YES
DC Reverse Polarity Protection YES
Insulation Resistance Protection YES
Ground Fault Protection YES
Output Over Current Protection YES
Output Short Circuit Protection YES
Output Over Voltage Protection YES
DC Isolator Switch YES
Surge Protection DC: Type II / AC: Type II
GENERAL DATA
Dimensions (W*H*D) mm 362W x 527H x 220D
Weight (Kg) 20.0
Topology Transformerless
Noise Emission (dB) <45dB
Display LED with LCD Display
Cooling Method Intelligent Fan Cooling
Operating Ambient Temperature (-25°C ~ +65°C)
Operating Humidity 0% – 100%
Max. Operating Altitude (m) 2000 (>2000m Derating)
Ingress Protection IP65
Standard Warranty 10 Years
CONNECTION TYPE
DC Connectors MC-4
Ingress AC Plug IP65 rated plug
Communication Modes WiFi / GPRS / RS 485 / Local Monitoring
Remote Monitoring YES
